Home / Motors / EC 82 Series Brushed DC motor
Ref.Number: EC Series
EC 82 Series Brushed DC motor
Specifications
Other: 2,4 Poles
Detail
MTM brush DC motor includes Industrial ,gearbox and transaxle motor series .
The diameter of motors has 63,71,82,90,105 and 124. Gearbox ,transaxle and electromagnetic are optional .
Besides application for power wheelchair and scooter, application can be medical bed, medical car, lifting solution, agriculture machine even aerial working vehicle ..etc.
We suggest a suitable motor according to customers' demands of application and provide appropriate suggestion for customers.

-------------------------------------------------------------------------------------------------------------------------
Motor: 24V / 750W
Gearbox Ratio: 1:48
Pole:4 P
IP44
Rated Output Speed: 4800 +/- 100 rpm
Rated Gearbox Motor torque: around 88 N-m
Recommend loading :200 KG each gearbox motor
Power-off Brake: 5 N-m without lever

-------------------------------------------------------------------------------------------------------------------------

Usage: Car, Electric Bicycle, Home Appliance, Scooter
Certification: ce, RoHS
Type: Brush Motor
Torque: 188 N-m
Gearbox: 1:48
Rated loading: 200KG
