The Lizard-100 series are compact portable borescopes that allow users to execute inspection in restricted spaces which could not be directly observed with naked eyes. The PMI Lizard-100 series set includes a portable device, a camera tube, a cleaning kit, a power adapter, a video connector, and a 4GB SD card. The portable device with 4.8” TFT LCD screen is capable of viewing, capturing and reviewing photos and video images. Images can also be displayed directly on a TV screen. The portable device is powered by rechargeable Li-Ion battery and a universal charger is included.

Portable device
Designation Lizard-100
Display 4.8" TFT LCD, 800 x 400 Pixels
Display Strength Tempered Glass
Interface
Micro USB 2.0 / AV out
Battery
Rechargeable Lithium Battery (3.7V)
Power adapter
100~240V AC in, 50/60Hz 0.12 A
5.0V DC out, 0.85A ~ 1A
Recording Medium Free 4G SD card
Photo Storage Format JPEG (640 x 480)
Storage Capacity Up to 20,000 pictures or 480 min. of video on 4 GB card
Video Recording Format AVI (640 x 480)
Video Out Format NTSC & PAL
Frame rate 30 fps
Compression Format MPEG4
Video size 10 min. (150 MB)
Working& Storage/ Battery charging temperature range -10 ~ 65 °C (14 ~ 149 °F)
Functions Snapshot, Video recording, Images (Photo & video) review on LCD screen, TV out, Transfer of photo & video from SD card to PC, Digital zoom
Magnifier 3 x
Battery Life 3 hours
Ingress Protection IP 54


Camera tubes
Designation US40 Series Us45 Series US50T Series UH50T Series
Tube type Semi-Rigid Hose
Tube Surface Treatment EPD /PE Cover PVC Cover
Image sensor CMOS Image Sensor
Resolution VGA (640 x 480 pixels)
Light Source 6 adjustable white LED s
Size tip diameter 4.0 mm 4.5 mm 5.0 mm
Tube length 1m, 2m, 3m 5m
Field of View (FOV) 80 °
Depth of Feild (DOF) 1 cm ~ 10 cm
Resistant to water & fuels Yes (For most fuels and solvents)
Min bending radius 50 mm
Working temperature range -10 ~ 65 °C (14 ~ 149 ° F)
Ingress Protection IP 67
