Home / Diagnostic Instrument / Medical catheter tube production line
Ref.Number: SYT-C50BA
Medical catheter tube production line
Detail
Corrugated Pipe & Hose Extrusion Line
-Model: STY-C50BA
-including: Extruder, Forming Machine, Haul-off machinie, on-line pinhole detector, cutting machine, classifier
-Material: PE, PP. EVA
-Pipe ID. Minimum: 12mm
-Pipe OD. Maximum: 50mm
-Pipe production capacity: 3-10/ 5-13/5-25 M/min.
-Extruder production capacity: 50-52/58-60/70-75 kg/hr
-Forming system: Blow
-Chain length: 3-3.2M/ 3.8-4M/5.8-6M
-Close chain length: 1250 / 1650 / 2650mm
-Drive motor: 3 / 5 / 5 HP
-Pairs of mold blocks: 60-64 / 76-80 / 118-120 pairs
-Mold cooling system: Air + Water separately
Medical catheter tube production line

Medical catheter tube production line
