General Specification

1. Structure is made of Stainless steel and processed with electro-polished.
2. Equipped with 8" central locking castor (inclusive of central controlled Brake & Free & Steer system)
3. Convenient brake and steer pedals are attached to the FOUR sides
4. When Backrest rises Bottom part will lower simultaneously to prevent patients from slide down. (for one direction only)
5. Patient can lie down in each direction. Both ends can be raised as the head part. Caregivers do not need to distinguish where the head part is while emergency situation
6. Backrest adjustable by gas spring mechanism
7. Dual hydraulic pedestal regulating the elevation and lean easily controlled by foot pedal attached on both sides.
8. Unique retractable guide wheel optimizes traction and cornering helping to reduce caregiver strain while improving overall mobility
9. Two Permanent I.V. poles (3 stage) at two ends
10. Four I.V. pole receptacles for extra I.V. poles
11. Three hooks for drainage bag attached to each side rail (Totally 6 hooks)
12. Trend & Rev. Trend Function
13. Low height for safer stretcher ingress and egress

Technical Specification

• Maximum weight limit: 350 kg (771 lbs.)
• Overall length: 210cm (include bumper wheel)
• Overall width: 80 cm (include bumper wheel)
• Height from floor to deck: 50(53)(55) cm (lowest) to 80(86)(90) cm (highest)
• Side rail length: 140 cm
• Side rail height above deck: 32 cm
• Mattress size: 64 cm x 185 cm
• Maximum head elevation: 90°
• Maximum Trendelenburg/Reverse Trendelenburg: 13°(15°)(17°)
• CASTER SIZE: 8" (20.3 cm)
